PROJECT SHOWCASE
Farmersville ISD
Multiple Greenheck RV units to satisfy outside air requirements. Greenheck’s Model RV: Pre-engineered rooftop ventilators deliver fresh outside air to a building that is tempered and dehumidified for space comfort. This unit is ideal for 100% outdoor air, variable air volume, and single zone applications.
MEP Engineer: Salas O' Brien
Chicken N Pickle – Grapevine, TX
HVLS fans are the perfect solution to provide circulation and destratification of the air for comfort of the Pickleball players yet not so much air movement to affect play or be a distraction.
Greenheck High Velocity Low Speed AMPLIFY DS-6: Powerful yet lightweight six-blade design provides high volume air movement that efficiently boosts occupant comfort and productivity in large coverage areas.
Greenheck Ceiling Exhaust Fan: Model SP ceiling exhaust fans are designed for clean air applications where low sound levels are desired.
MEP Engineer: PKMR Engineers
DFW Commerce Center
Greenheck adjustable extruded aluminum louvers: Model EAD-635 is an adjustable extruded aluminum louver with drainable style blades. Compatible with electric actuators with factory installed option and highest intake volume capacity in its class.
Greenheck direct gas-fired make-up air units: Model DGX is a highly configurable direct gas-fired heating and cooling system. The unit incorporates a modular design to maximize configuration flexibility. In addition, constant volume, 100% outdoor air, recirculation, and VAV airflow arrangement are available. The DGX can be configured with a forward-curved, backward-curved or mixed flow plenum supply fan allowing for either belt-driven or drive arrangements.
Roof-mounted centrifugal downblast direct drive exhaust fans: The model G is a direct drive, spun aluminum fan, designed for roof mounting on a curb for general, clean air exhaust applications. Units feature a spun aluminum housing and have certifications including seismic, high wind and hurricane.
More info: HOME | dfw-commerce (dfwcommercecenter.com)
Sam Houston Middle School
For well over 30 years, Seasons•4 has specialized in building Custom Multizone units. Where others may dabble in a market, Seasons•4 immerses themselves in it. Whether your need is a direct replacement of an existing multizone unit or a new custom multizone unit, Seasons 4 has a unit that is right for your needs.
Hotel Indigo, Irving, TX
Greenheck 100% outside air units: An inverter compressor is standard for the lead compressor from 3 to 70 tons. The inverter compressor provides many benefits:
Improved part load efficiency
Integrated Energy Efficiency Ratio (IEER) up to 21.4, with an average improvement over a digital scroll compressor of 15 to 20%
Reduced sound levels
Precise temperature and humidity control
MEP Engineer: James F Turner Engineers
Triangle Brick Manufacturing Plant
Greenheck Axial wall exhaust fans are ideal for factory and warehouse applications where high volumes of air and low pressures are required. These Greenheck fans represent the most comprehensive wall axial exhaust fan line in the industry. Model AER direct drive fans with expanded performance range specifically designed for wall mounted clean air applications. Units feature cast aluminum airfoil or fabricated steel blades and hubs. Available in a full range of sizes between 20 and 60 inches.
Greenheck offers motor starters for both single phase and three phase motors in commercial and industrial applications. These include basic motor protection and advanced motor protection, SmartStart™. All Greenheck motor starters are available in either indoor or outdoor enclosures. An MSAC offers an innovative and versatile design with hand/off/auto capability and class 10 or 20 electronic overload (1-40 FLA). The unit provides LED status indicators in case of faults and provides advanced control capability for dampers, fireman's override, shutdown, permissive auto, and fault status. The MSAC is available with an optional disconnect for manual control of input power. Available in NEMA-1, NEMA-3R and NEMA-4X enclosures.
More info: Triangle Brick Manufacturing Plant (r-o.com)
Medical City Dallas
Medical City Dallas had a need to upgrade the humidity control equipment to insure proper conditions in their operating room.
Ultra-sorb Model MP is a multi-purpose humidifier dispersion panel for both pressurized and atmospheric steam applications in AHUs or ducts.
DriSteem’s STS® (steam-to-steam) humidifier creates chemical-free humidification steam using boiler steam as its energy source. Boiler steam in the heat exchanger vaporizes clean fill water into humidification steam. No boiler steam or chemicals ever enter the humidified space, instead they return to the boiler.
More info: Medical City Dallas Master Plan | Brasfield & Gorrie (brasfieldgorrie.com)
MEP Engineer: Campos Engineering
The Outlook at Windhaven
Pool unit: Dry-O-Tron DS Series - Advanced Dehumidification Technology
Our DRY-O-TRON DS Series line of dehumidifiers provide the very best in classic compressorized humidity control. The combination of exceptional engineering and design, plus premium components makes our DRY-O-TRON DS Series both energy efficient and exceptionally reliable. The DRY-O-TRON DS Series provides peak performance in the range of 12 to 120 lbs per hour of moisture removal and 600 to 6,500 CFM of air handling. For larger applications, our LEEDeR® Series is an ideal solution.
More info: Home - The Outlook at Windhaven
MEP Engineer: Jordan & Skala
Bell County Jail Facility
The Bell County Jail Facility required a number of different exhaust needs.
Exhaust fans: Greenheck G, CUE, CUBE, AX axial upblast, USF centrifugal blowers
Make-up air: The Greenheck SAF is a belt drive, filtered supply fan, designed to provide non-tempered, filtered make-up air in commercial and industrial applications. These units feature a forward-curved wheel and galvanized steel housing.
Greenheck FGI Gravity Ventilators designed for intake applications with natural gravity or negative pressure systems. Units feature a low silhouette, fabra hood style housing.
The FumeJet® exhaust fan is a pre-engineered, centrifugal exhaust system. Its design allows for safe exhaust and dispersion of contaminated air in commercial, institutional or industrial applications. FumeJet offers quick and easy package installation; slip-fit stack connections, inlet collar and optional equipment supports. The FumeJet exhaust fan simplifies an installation with options available to configure each unique application as an alternative to a field built-up system. The fan and stack assembly has been designed and factory tested to withstand a force of 34 PSF (equivalent to 115 mph) without the need for guy-wires.
More info: BELL COUNTY JAIL FACILITY – Brinkley Sargent Wiginton Architects (bsw-architects.com)
MEP Engineer: MD Engineering
Dallas ISD, Sunset High School
Greenheck dedicated outside air systems (DOAS) were the perfect solution for this renovation project. Greenheck Model RV units are available in 3 to 70 tons with options for DX cooling or chilled water cooling and natural gas, hot water, electric or air source heat pump heating.
MEP Engineer: B&H Engineers
Pierce-Burch Water Treatment Plant Improvements Project
Indeeco’s explosion-proof convector is designed to provide a heavy duty and corrosion resistant heat source.
Triad® Washdown & Corrosion Resistant Unit Heater: The Indeeco Triad unit heater is the perfect solution to the problem of heating people or equipment in non-hazardous environments where moisture and corrosion exist.
MEP Engineer: KWH Engineering
Addison Athletic Club
The City of Addison Athletic Club is a multifaceted community center with a number of great amenities, including an indoor pool. The Dry-O-Tron DS Series by Dectron was the ideal solution with 24/7 internet monitoring, 100% corrosion protection and the smallest footprint in the industry.
More info: Addison Athletic Club | CIVIC & GOVERNMENT (northridgecg.com)
MEP Engineer: MEP Consulting Engineers
Meehan’s Chophouse & Henry’s Cigar Lounge
Greenheck Dedicated Outdoor Air Systems for high percentage and 100% outside air
2-inch double-wall cabinet with R13 injected foam insulation
500 to 18,000 cfm and up to 3 in. wg ESP
Ideal for 100% outdoor air, variable air volume, and single zone applications
Enthalpy wheel or enthalpy core options
Direct drive, VFD driven, plenum supply/ exhaust fans
Optional recirculation damper for 20-100% outside air and night setback operation
Optional horizontal duct configurations for side return and supply
More info: Nationwide Construction - Built by NWC : Meehan's Chophouse
MEP Engineer: Nova Engineering
Hilton Garden Inn, Longview
Pool unit replacement:
Dry-O-Tron DS Series Advanced Dehumidification Technology
Our DRY-O-TRON DS Series line of dehumidifiers provide the very best in classic compressorized humidity control. The combination of exceptional engineering and design, plus premium components makes our DRY-O-TRON DS Series both energy efficient and exceptionally reliable. The DRY-O-TRON DS Series provides peak performance in the range of 12 to 120 lbs per hour of moisture removal and 600 to 6,500 CFM of air handling. For larger applications, our LEEDeR® Series is an ideal solution.
StarCorr Sheets
Greenheck axial upblast exhaust fans are a cost-effective option for low to medium pressure applications. Roof-mounted models are designed to discharge clean air or fume exhaust up and away from the building. Typical uses are industrial space, warehouses, fume exhaust, and paint booth exhaust. Models are available in spark resistance construction, emergency smoke or continuous high-temperature exhaust. Select from direct and belt drive fans with cast aluminum or fabricated steel blades based upon application requirements.
The motor mounted on model TAUB-L/H is out of the airstream. This makes it suitable for clean air, high-temperature process exhaust or high-temperature emergency smoke removal. The TAUB-L/H has rolled damper blades, gasket covered edges, fully welded and coated housing with steel blades. Its maximum continuous operating temperature is 500 °F.
Model EACA-601 is an extruded aluminum combination louver-damper with drainable style blades, airfoil style damper blades and concealed damper linkage within the louver jambs. When in the open position this louver functions as a conventional louver while providing tight shut off from air and other elements when in the closed position. This product is most often provided with factory-mounted and adjusted electric actuators.
More info: StarCorr Sheets | Taylor, the Builders (taylorthebuilders.com)
ClearSky Rehabilitation Hospital of Mansfield
Greenheck Dedicated Outdoor Air Systems for high percentage and 100% outside air. Pre-engineered rooftop ventilators deliver fresh outside air to a building that is tempered and dehumidified for space comfort. Models RV, RVE, and RVC include a microprocessor controller that is factory programmed, wired and tested prior to shipment. The controller can operate stand-alone or integrate with a Building Management System (BMS) using BACnet® MS/ TP or IP, or Modbus® RTU or IP protocols. This controller is responsible for operating the unit in a safe and energy-efficient manner while controlling temperature and humidity.
MEP Engineer: IMEG Corp.
QTS Data Center
Dristeem XT Series electrode humidifiers provide humidification for a wide range of buildings, including health care, commercial, industrial, and government facilities. Easy installation and cylinder replacement together with minimal maintenance make XT Series one of the most affordable humidification systems to purchase and install.
Dristeem Space distribution units (SDUs) and steam blowers mount on top of humidifiers or remote from the steam generator to disperse steam within an open space. SDUs disperse steam generated by non-pressurized steam generators such as DriSteem’s Vaporstream® and Vapormist® humidifiers, XTP steam blowers disperse steam from XTP humidifiers, XTR steam blowers or fan pack disperse steam from XTR humidifiers.
More info: Construction Blog: Irving, TX DC3 | QTS Data Centers
MEP Engineer: KW Mission Critical Engineering
Home2 Suites, Flower Mound
Pool unit replacement:
Dry-O-Tron DS Series Advanced Dehumidification Technology
Our DRY-O-TRON DS Series line of dehumidifiers provide the very best in classic compressorized humidity control. The combination of exceptional engineering and design, plus premium components makes our DRY-O-TRON DS Series both energy efficient and exceptionally reliable. The DRY-O-TRON DS Series provides peak performance in the range of 12 to 120 lbs per hour of moisture removal and 600 to 6,500 CFM of air handling. For larger applications, our LEEDeR® Series is an ideal solution.
Product features:
Compact vertical and horizontal designs
Models DS-10 to DS-35 fit through a 32” doorway, ideal for retrofit applications
Horizontal units from DS-20 to DS-102 available for indoor or outdoor applications
Multiple supply air connection options to provide maximum flexibility
Outdoor air connection for code-required minimum ventilation is built-in, complete with filter and manually adjustable damper
Godley High School, Phase 2
Greenheck’s Model RV: Pre-engineered rooftop ventilators deliver fresh outside air to a building that is tempered and dehumidified for space comfort. This unit is ideal for 100% outdoor air, variable air volume, and single zone applications.
An inverter compressor is standard for the lead compressor from 3 to 70 tons. The inverter compressor provides many benefits:
Improved part load efficiency
Integrated Energy Efficiency Ratio (IEER) up to 21.4, with an average improvement over a digital scroll compressor of 15 to 20%
Reduced sound levels • Precise temperature and humidity control
MEP Engineer: Romine, Romine & Burgess
Meow Wolf
Source: New Portals and Cross-Exhibition Connections in Grapevine, TX | Meow Wolf
The Greenheck QEI is a mixed flow fan for commercial, institutional, and industrial applications handling everything from clean air to high temperature exhaust. Model offers multiple construction levels to match the application providing best performance at the most economical solution. Features performance enhancing airflow straightening vanes and easily accessible motor outside of the airstream. The QEI model has a variety of mounting options for indoor and outdoor locations.
The Greenheck centrifugal utility set or blower can be utilized in a wide selection of indoor or outdoor, supply or exhaust applications. These can be anything from commercial light to medium-duty general ventilation requirements to those requiring high airflows, manufacturing process, emergency, continuous high-temperature, or grease-laden exhaust. Units have many discharge configurations, which allow different airflow direction without system losses from duct turns. They are fabricated of steel with a wide range of corrosion resistant coatings. Housing designs offered are either lock-seam or fully welded construction. Choice of forward curved, backward inclined, or higher efficiency airfoil centrifugal wheels is available as standard. Options include aluminum or stainless steel wheels. Prior to shipment, each fan assembly is factory run and tested for quality assurance.
Cleburne ISD Lowell Smith Middle School Renovations
Greenheck Dedicated Outdoor Air Systems for high percentage and 100% outside air. Pre-engineered rooftop ventilators deliver fresh outside air to a building that is tempered and dehumidified for space comfort. Greenheck Model RV units are available in 3 to 70 tons with options for DX cooling or chilled water cooling and natural gas, hot water, electric or air source heat pump heating.
MEP Engineer: Leaf Engineers
Baylor Scott & White Outpatient Rehabilitation
Swimming pool unit: Dectron DRY-O-TRON DS Series provides the very best in classic compressorized humidity control. Proven engineering and design, plus premium components makes DRY-O-TRON DS Series both energy efficient and exceptionally reliable. With WebSentry Technology as a standard feature our DS Series is monitored 24-7 via the Internet and backed by Dehumidified Air Services, our exclusive national network of factory-direct service personnel.
Eastfield’s new Student Success Center and Academic Building
Greenheck model XG-TH-500 is the simplest and most widely used VAV terminal unit. Its basic components are an insulated sheet metal box, round inlet damper, flow measuring device and a rectangular outlet. The primary function is to regulate airflow to an occupied space. The XG-TH-500 can come with a heating coil on the discharge of the unit to provide for reheat, when necessary.
Greenheck model XG-FVI-500 Series air terminal units provide superior comfort to zones by intermittent parallel fan operation. Conditioned primary air is varied during cooling while the fan cycles on during heating. Parallel fan-powered terminal units allow for recovery of waste heat from the return plenum and a potential reduction in central fan energy.
More info: Plans for $62.4 million building move forward – The Et Cetera (eastfieldnews.com)
MEP Engineer: KAI Texas
APN Addiction Recovery Center
Greenheck Dedicated Outdoor Air Systems for high percentage and 100% outside air
2-inch double-wall cabinet with R13 injected foam insulation
500 to 18,000 cfm and up to 3 in. wg ESP
Ideal for 100% outdoor air, variable air volume, and single zone applications
Enthalpy wheel or enthalpy core options
Direct drive, VFD driven, plenum supply/ exhaust fans
Optional recirculation damper for 20-100% outside air and night setback operation
Optional horizontal duct configurations for side return and supply
MEP Engineer: SW Associates
Home2 Suites, Dallas
Greenheck Dedicated 100% Outdoor Air Unit
Pre-engineered rooftop ventilators deliver fresh outside air to a building that is tempered and dehumidified for space comfort. This unit is ideal for 100% outdoor air, variable air volume, and single zone applications.
Biolabs At Pegasus Park
HIGH PLUME DILUTION LABORATORY EXHAUST FANS
The high plume nozzle and dilution windband entrain outside ambient air to assist in the increased dilution of laboratory exhaust while maintaining effective plume height. Higher nozzle velocity creates a higher dilution, diluting and dispersing potentially hazardous exhaust or fumes quickly and safely.
More info: BioLabs Coworking Lab opens at Pegasus Park in Dallas - Montgomery Street Partners
MEP Engineer: CRB USA
Springhill Suites, Irving
Swimming pool air conditioning/dehumidifier: Dectron DRY-O-TRON DS Series provides the very best in classic compressorized humidity control. Proven engineering and design, plus premium components makes DRY-O-TRON DS Series both energy efficient and exceptionally reliable. With WebSentry Technology as a standard feature our DS Series is monitored 24-7 via the Internet and backed by Dehumidified Air Services, our exclusive national network of factory-direct service personnel.
Cook Childrens Dodson Specialty Clinics
Greenheck High Plume Laboratory Exhaust Fans
Greenheck Vektor® fans with high-velocity discharge nozzles have multiple nozzle sizes available for each fan. These provide options in plume height, sound levels and energy consumption requirements, for any lab project application. These fans are cost-effective solutions compared to the field built-up fan and stack assemblies.
The Vektor-H utilizes a direct or belt-driven, tubular centrifugal fan with an efficient conical nozzle designed to propel fumes safely away from the building. These fans can be configured in single, double or triple fan systems.
MEP Engineer: Smith Seckman Reid
Fairfield Inn, Corinth
Dry-O-Tron DS Series Advanced Dehumidification Technology
Product features:
Compact vertical and horizontal designs
Models DS-10 to DS-35 fit through a 32” doorway, ideal for retrofit applications
Horizontal units from DS-20 to DS-102 available for indoor or outdoor applications
Multiple supply air connection options to provide maximum flexibility
Outdoor air connection for code-required minimum ventilation is built-in, complete with filter and manually adjustable damper
Prologis Park 121
Powered Aire 108” Ten-Fourteen Door (TFD) unheated air curtain. Our TFD industrial air door is perfect for medium-sized dock doors in industrial environments. Designed for doors & openings up to 14 feet high.
More info: Prologis Park 121 | Prologis Property Search
McKinney Municipal Service Center North Campus
CAR-MON vehicle exhaust system composed of overhead hose reel storage suspension system, diesel cane exhaust capture and exhaust fans.
Greenheck HVLS: AMPLIFY DS-6 - Powerful yet lightweight six-blade design provides high volume air movement that efficiently boosts occupant comfort and productivity in large coverage areas.
Greenheck Model ESD-635 is an extruded aluminum stationary drainable louver that protects air intake and exhaust openings in exterior walls. The drainable head and stationary horizontal drainable blades collect and further channel water to the vertical downspouts located in the louver jambs where gravity takes effect, allowing water to escape at the louver sill.
The INDEECO UHIR unit heater is available in 50 standard models with ratings up to 50 KW at voltages of 208, 240, 277, and 480 single or three-phase. They are available with a wide variety of factory built-in or field-installed options.
More info: Municipal Architects — Municipal Architects Dallas-Fort Worth (qarch.com)
MEP Engineer: Baird, Hampton, Brown
TSTC Plumbing Facility
Car-Mon Products offers a full line of filtration units and dust collectors. These products are built to an industrial-grade strength and quality to serve a wide range of industries.
Designed for modular expansion, quick installation and longevity these products our proudly built in the USA. Our equipment offerings range from static systems for light dust loading to heavy dust loading dynamic systems with self-filter cleaning options and product reclamation.
Model CMX filter unit is designed to clean contaminated air and fine nuisance dust. It shall be provided as a self-contained package with a filter and exhaust fan with hanging support lugs. The contaminated air will travel through the inlet side of the cabinet and into a three stage filtering process. The first stage aluminum pre-filter shall protect against sparks and hot embers, the second stage shall be a be MERV 8 high capacity fabric filter and a final stage MERV 15 final filter.
Dallas ISD Career Institute
Roberts Gordon Infrared tube heaters. This project had six 40 foot infrared heaters with aluminized tubes and aluminum reflectors.
GORDONRAY® DF - Two Stage Infrared Heating: Standard product features include dual burner status indicator lights and convenient external thermostat connection to power a low voltage thermostat. This infrared heater offers a hinged burner box door providing easy access to electrical components. With quick service and maintenance in mind, the burner box has an internal partition separating combustion air from the electrical components. Like our other unitary infrared heaters, the GordonRay DF has flexible layout options that include straight, u-tube, or "L" configurations along with a broad range of burner sizes and tube lengths.
MEP Engineer: Meza Engineering
University of North Texas Discovery Park
EBTRON Airflow and Temperature Measurement Device with Integral Relative Humidity Sensor (with /H option).
The GTx116e-PC is EBTRON’s top-of-the-line solution for accurate and repeatable measurement in ducts and plenums. Ruggedized RH sensor option (/H), onboard barometric pressure sensor and velocity-weighted temperature results in accurate relative humidity, enthalpy and dew point calculations. Ideal for supply, return and outdoor air intake applications on systems with an airside economizer. Bluetooth® low energy technology interface.
The Greenheck FumeJet® exhaust fan is a pre-engineered, centrifugal exhaust system. Its design allows for safe exhaust and dispersion of contaminated air in commercial, institutional or industrial applications. FumeJet offers quick and easy package installation; slip-fit stack connections, inlet collar and optional equipment supports. The FumeJet exhaust fan simplifies an installation with options available to configure each unique application as an alternative to a field built-up system. The fan and stack assembly has been designed and factory tested to withstand a force of 34 PSF (equivalent to 115 mph) without the need for guy-wires.
More info: Discovery Park | College of Engineering (unt.edu)
MEP Engineer: Halff Associates
Fair Park Coliseum
EBTRON Airflow Measurement with Temperature and Alarm Capability
The GTx116e‐P+ is EBTRON’s top‐of‐the‐line solution for accurate and repeatable measurement in ducts and plenums. Ideal for outdoor air delivery monitoring and airflow tracking applications. Temperature and alarm capability plus unsurpassed product features and connectivity options make this the best choice for today’s high performance buildings. Bluetooth® low energy technology interface.
Plano Fire Rescue Training Center
Model EHH-601 protects air intake and exhaust openings in exterior walls sensitive to water penetration. The design features a drainable head. Horizontal rain resistant blades provide exceptional resistance to wind driven rain.
GORDONRAY® DF - Two Stage Infrared Heating: Standard product features include dual burner status indicator lights and convenient external thermostat connection to power a low voltage thermostat. This infrared heater offers a hinged burner box door providing easy access to electrical components. With quick service and maintenance in mind, the burner box has an internal partition separating combustion air from the electrical components. Like our other unitary infrared heaters, the GordonRay DF has flexible layout options that include straight, u-tube, or "L" configurations along with a broad range of burner sizes and tube lengths.
More info: Plano Fire Training Center – Brinkley Sargent Wiginton Architects (bsw-architects.com)
MEP Engineer: MD Engineering
Holiday Inn, Garland
Indoor pool air conditioning unit replacement:
Dry-O-Tron DS Series Advanced Dehumidification Technology
A Really Clever Concept: This ingenious innovation provides twice the dehumidification in the same footprint as a regular unit. It’s a compact, two-stage system that provides scalable capacity and performance of two complete systems in one, controlled by a single, sophisticated brain.
Perfect for Retrofit: Designed specifically for retrofit situations, the Dry-O-Tron DS-D Series offers double capacity with a smaller footprint.
Two systems in one package: Ability to split systems – with just a wire harness to connect them.
The smallest footprint in the industry!
Compact vertical and horizontal designs
Models DS-10 to DS-35 fit through a 32” doorway, ideal for retrofit applications
Horizontal units from DS-20 to DS-102 available for indoor or outdoor applications
Multiple supply air connection options to provide maximum flexibility
Outdoor air connection for code-required minimum ventilation is built-in, complete with filter and manually adjustable damper
Lake Dallas ISD Multipurpose Indoor Practice Facility
Indeeco’s UHIR Series Unit Heaters provide economical comfort heating for a wide range of applications. The UHIR unit heater is available in 50 standard models with ratings up to 50 KW at voltages of 208, 240, 277, and 480 single or three-phase. They are available with a wide variety of factory built-in or field-installed options.
Greenheck Model ESD-635 is an extruded aluminum stationary drainable louver that protects air intake and exhaust openings in exterior walls. The drainable head and stationary horizontal drainable blades collect and further channel water to the vertical downspouts located in the louver jambs where gravity takes effect, allowing water to escape at the louver sill.
Greenheck Model SQ is a direct drive square centrifugal inline fan designed for intake, exhaust, return or make-up air applications where space is a major issue. Units feature a galvanized steel housing and aluminum backward-inclined wheel.
MEP Engineer: DBR Engineering
